地埋線探測儀使用方法

　     Methods of using buried line detectors

　　使用地埋線探測儀的步驟如下：

　　The steps to use a buried wire detector are as follows:

　　1.準備設備。確保地埋線探測儀放置在平穩的地面上并插入電源，正確安裝探測線圈并校正設備以確保探測準確性。

　　1. Prepare the equipment. Ensure that the buried wire detector is placed on a stable ground and plugged into the power supply, correctly install the detection coil, and calibrate the equipment to ensure detection accuracy.

　　2.發射機設置。開機后長按電源鍵，選擇檢測頻率并確認，調節輸出檔位和輸出功率，確保連接穩固并接觸良好。

　　2. transmitter settings. After turning on, press and hold the power button, select the detection frequency and confirm, adjust the output gear and output power to ensure a stable connection and good contact.

　　3.接收機設置。開機后選擇與發射機相同的檢測頻率，選擇檢測模式（寬峰、峰值、峰值箭頭、谷值），調節增益，使用測深按鍵進行測深。

　　3. Receiver settings. After turning on, select the same detection frequency as the transmitter, select the detection mode (wide peak, peak, peak arrow, valley), adjust the gain, and use the depth measurement button for depth measurement.

　　4.直連法操作。確保連接穩固，將輸出線紅色魚夾與測試樁測試線連接，黑色魚夾拉與管道走向垂直方向，黑色接地線完全插入土壤中，選擇潮濕濕潤的土壤。

　　4. Direct connection method operation. Ensure a stable connection, connect the red fish clip of the output line to the test line of the test pile, pull the black fish clip perpendicular to the direction of the pipeline, fully insert the black grounding wire into the soil, and choose a damp and moist soil.

　　5.探測操作。將探測線圈靠近地面并沿著要探測的區域慢慢移動，當探測線圈上的指示燈亮起時，表示該位置探測到了地埋線。

　　5. Detection operation. Move the detection coil closer to the ground and slowly along the area to be detected. When the indicator light on the detection coil lights up, it indicates that the buried line has been detected at that location.

　　6.數據處理。使用自帶的數據處理軟件對數據進行處理和分析，將設備連接到電腦上，打開數據處理軟件，將探測儀中存儲的數據導入到軟件中進行處理。

　　6. Data processing. Use the built-in data processing software to process and analyze the data, connect the device to the computer, open the data processing software, and import the data stored in the detector into the software for processing.

　　此外，在使用地埋線探測儀時，應注意，避免在強磁場、電磁干擾、電力交流強干擾等環境下使用，確保探測數據的準確性和可靠性。

　　In addition, when using underground wire detectors, safety should be taken into consideration to avoid using them in environments with strong magnetic fields, electromagnetic interference, and strong electrical and AC interference, ensuring the accuracy and reliability of detection data.
